Beskrivelse
Maximum fluid working pressure
7 bar (0.7 MPa, 100 psi)
Air pressure operating range
1.4-7 bar (0.14-0.7 MPa, 20-100 psi)
Maximum air consumption
0.8 m3/min (28 scfm)
Air consumption at4.8 bar/76 l (70 psi/20 gpm)
0.51 m3/min (18 scfm)
Maximum free-fl ow delivery
61 l/min. (16 gpm)
Liters (gallons) per cycle
0.15 (0.04) with standard diaphragms
0.11 (0.03) with overmolded diaphragms
Maximum suction lift
7.6 m (25 ft) wet
4.6 m (15 ft) dry
Maximum size pumpable solids
2.38 mm (3/32 in)
Air inlet size
1/4 npt(f)
Fluid inlet/outlet size (sanitary flange)
Weight – All models
10.25 kg (22.6 lb)
