QIF OX1‑B Series – Oxygen-cleaned full‑bore threaded ball valve with ISO 5211 top mount
Stainless steel actuator‑ready valve (CF8M body, SS316 ball) cleaned and certified for oxygen service
Supplied bare stem with ISO 5211 actuator pad; no handle included to reduce contamination risk
Degreased and hydrocarbon-free, with V‑type PTFE packing and Viton O‑ring for secure, clean sealing
For safe installation, use dry, particle‑free fittings; avoid grease; cycle monthly
- Available DN15 to DN100; BSPP threads standard, NPT optional
- Minimal flow resistance with full‑bore floating ball; blow‑out‑proof stem
- Pressure-rated up to 1 200 psi; operating temperature −25 °C to +180 °C
- API 598 tested; maintenance and actuator sizing per technical guide
